Seltrik 5000VA 48V MPPT Lithium-ion Supported Solar Inverter

In stock - 5 items available
SKU: SKL5048
Rs. 48,599.00
Sale Rs. 85,999.00 Rs. 48,599.00
Color

Use this text to encourage communication or promote sharing on social networks.

You can also add links

The Seltrik 5000VA 48V Lithium-ion MPPT Solar Inverter combines superior quality with advanced MPPT technology for unmatched performance. Operating with an input voltage of 120V ±5V, it ensures efficient low-voltage charging and optimizes solar energy utilization from the first rays of sunlight, even during rainy seasons.

Brand
  • Seltrik
Model Number
  • 5000VA 48V MPPT Lithium-ion Supported Solar Inverter
Battery Included
  • No
Back Up Time
  • 4 hrs
Load Options
  • 17amp, AC, submersible, Refrigerator, Washing machines, Mixer grinder, LED
Type
  • Pure Sine Wave Inverter
Model Name
  • Seltrik 5000VA 48V MPPT Lithium-ion Solar Inverter
Mode Type
  • solar off grid Inverter
Material
  • metallic
Fixture Type
  • NA
Technology Used
  • MPPT technology
Solar Power Compatible
  • Yes
Switch Type
  • Relay
Output Features
Efficiency
  • 85 %
Output Voltage
  • 220V±8%
Output Frequency
  • 50Hz±1%
Overload
  • >100%,15Sec
AC Output Types
  • MPPT
Change Over Time
  • 12 ms
Change Over Voltage
  • 220V
Surge Rating
  • 5000 VA
Overload Rating
  • 25A
Other Output Features
  • NA
Input Features
Input Voltage
  • 230V
Input Frequency
  • 50Hz±3%
Low Cut Input Voltage
  • 120V±5V
Low Cut Recovery Input Voltage
  • >130V±5V
High Cut Input Voltage
  • 290V±5V
High Cut Recovery Input Voltage
  • <280V±5V
Other Input Features
  • multiple charging settings
Battery Features
Battery Type
  • Lithium-ion/LEAD ACID/SMF
Recharge Time
  • NA
Number of Batteries
  • 2
Battery Boost Voltage
  • 57V
Battery Voltage
  • 24V
Battery Capacity
  • 220Ah
Battery Charging Current
  • 15A BY GRID/20A BY SOLAR
Replacement Battery
  • No
Replacement Battery Type
  • NA
Compatible Battery Types
  • Lithium battery
Compatible Battery Make
  • Compatible with all battery brand
Other Battery Features
  • High Efficiency
Environmental Features
Storage Temperature
  • 40C
Operating Temperature
  • 40C
Noise Level
  • <55dB,distance 1m
Total Harmonic Distortion
  • <5%
Other Environmental Features
  • environment friendly
Convenience Features
Emergency Power Off
  • Yes
Display Type
  • LCD
Display Indicator Functions
  • Input/Output Voltage, Current, Frequency, battery voltage & current, Solar Voltage & Current, charging set, ups mode or inverter mode, power On/off
Audible Indicator Functions
  • over load, grid fail ON/OFF
USB Charging Port
  • Yes
Protection Against
  • short circut, battery low, high temp., over load
Cooling System
  • Fan
Other Convenience Features
  • low maintenance
Dimensions
Width
  • 35 cm
Height
  • 52 cm
Depth
  • 70 cm
Weight
  • 30 kg
Additional Features
Certification
  • BIS Certified
Corrosion Resistant
  • Yes
Other Features
  • high efficiency, by pass switch, soft start technology, user friendly, over temp protection, noise free device
Warranty
Warranty Summary
  • 36
Service Type
  • all spare part
Covered in Warranty
  • any power related
Not Covered in Warranty
  • broken and repair not covered
