2kVA 24V Solar Inverter With 12.8 V inbuilt Lithium Ion battery SKLT2024N
Couldn't load pickup availability
Use this text to encourage communication or promote sharing on social networks.
The 2kVA 24V Table Top Solar Inverter with 12.8V Inbuilt Lithium-Ion Battery is a compact and efficient power backup solution designed for modern homes and small commercial spaces. This advanced system integrates a solar inverter and lithium battery into a single table top unit, offering a space-saving and easy-to-install solution. Unlike traditional inverter setups that require separate batteries and complex wiring, this all-in-one design simplifies installation and keeps the setup clean and organized, making it ideal for homes, offices, and small businesses.
Powered by advanced lithium battery technology, the inverter delivers faster charging, higher efficiency, and a longer service life compared to conventional lead-acid systems. It also supports solar and grid charging, enabling users to utilize renewable energy while ensuring uninterrupted power supply. With built-in safety features that protect against overcharging, deep discharge, overload, overheating, and short circuits, the system ensures reliable and safe performance for everyday power backup needs.
Key Benefits:
-
Fast Charging (Approx. 4.5 Hours)
-
Built-in Battery Management System (BMS)
-
Long Battery Life (3000–3500 cycles)
-
Charging even at low voltage
-
Automatic low & high voltage cut-out
-
Overload & short circuit protection
-
24×7 backup capability
Specifications
|
Parameter
|
SKLT2024P (Table Top) |
| Rating | 2000 VA |
| Switching Element | MOSFET |
| Controller | 32 Bit |
| Nominal DC Voltage | 25.6 V |
| Charging Mode | Solar / Grid Priority |
| Dimensions (L×B×H mm) | 380 × 286 × 290 |
| Weight | 28 kg |
Solar Parameters
| Parameter | SKLT2024P |
| Solar Input Range (PWM) | 31V – 60V |
| Maximum Current | 50A |
Inverter Parameters
| Parameter | Specification |
| Output Voltage | 220V ± 8% |
| Output Frequency | 50Hz ± 1 |
| Maximum Load | 800W / 1200W / 1600W (Bulb Load depending on model) |
| Isolation Transformer | Inbuilt |
| Crest Factor | 03:01 |
| Output Waveform | Pure Sine Wave |
| THD (Linear Load) | < 3% |
| THD (Non-Linear Load) | < 5% |
| Overload | >100% for 15 seconds |
| Inverter Efficiency | >85% |
| Changeover Time (Inverter → Mains) | <10 ms |
| Changeover Time (Mains → Inverter) | <12 ms |
Battery Parameters
| Parameter | SK10024L |
| Battery Voltage | 25.6 V |
| Battery Capacity | 100 Ah |
| Battery Energy | 2560 Wh |
| Series Cell | 8S |
| Number of Cells | 8 |
| Standard Charge Current | 100A |
| Cut-off Voltage (25°C) | 21.6 V |
| Round Trip Efficiency | >98% |
| Calendar Life | >10 Years |
| Cycle Life (80% DOD) | 3500 Cycles |
Operating Temperature
| Condition | Temperature |
| Charging | 0°C – 60°C |
| Discharging | -20°C – 60°C |
BMS Protections
| Parameter | Specification |
| Charging Voltage Cell Protection | 3.75V Protection / Recovery @ 3.1V |
| Discharging Voltage Cell Protection | 2.5V Protection / Recovery @ 3.1V |
| Normal Charging Current | <50A |
| Normal Discharging Current | 100A |
| Over Current Protection 1 | >100A and <120A (Delay 30s) |
| Over Current Protection 2 | >120A and <150A (Delay 30s) |
| Short Circuit Protection | 2200A Delay 1ms |
